KUKA KR50 R2500-2 D01 KRC5

Detalles del robot

The KUKA KR50 R2500‑2 D01 is a powerful 6‑axis industrial robot designed for intelligent automation and modern production systems.
It is widely used in smart factories where precision, speed, and reliability are required.

This robot has a payload capacity of 50 kg and a maximum reach of about 2500 mm, making it suitable for handling medium to heavy loads.
Thanks to its advanced mechanical structure and high‑performance motors, it can operate with high accuracy and repeatability.

The robot is controlled by the KUKA KRC5 controller, which supports integration with artificial intelligence, vision systems, sensors, and Industry 4.0 solutions.
This allows the robot to work in automated lines, improving productivity and reducing human error.

The KR50 R2500‑2 D01 is ideal for companies looking for a flexible robotic solution that can adapt to different industrial applications.

Aplicaciones robotizadas

• Prensa tendiendo
• Carga y descarga de piezas
• Mecanizado
• Manipulación de piezas
• Soldadura por arco
• Soldadura de punto
• Paletización
• Medición

Technical Information – Specifications

• Manufacturer: KUKA
• Model: KR50 R2500‑2 D01
• Controller: KUKA KRC5
• Robot type: Industrial robotic arm
• Number of axes: 6
• Rated payload: 50 kg
• Maximum payload: up to 62 kg
• Maximum reach: 2501 mm
• Pose repeatability: ±0.05 mm
• Mounting positions: Floor, wall, ceiling, angled
• Protection rating: IP65 (robot body), IP67 (wrist)
• Operating temperature: 0 °C to +55 °C

These characteristics make the robot suitable for continuous industrial operation and advanced automation environments.

The KUKA KR50 R2500‑2 D01 uses high‑performance electric motors on each axis.
The maximum speeds (with rated payload) are:

• Axis A1: 175 °/s
• Axis A2: 158 °/s
• Axis A3: 175 °/s
• Axis A4: 250 °/s
• Axis A5: 250 °/s
• Axis A6: 360 °/s

These speeds allow fast cycle times, smooth movements, and precise positioning, even in complex robotic tasks.

Applications – Industrial Use

The KUKA KR50 R2500‑2 D01 is commonly used in the following industrial fields:

• Material handling
  Automatic movement of parts and components

• Assembly operations
  Precise and repeatable mounting of mechanical parts

• Palletizing and depalletizing
  Stacking and unstacking products on pallets

• Packaging systems
  Automated packing lines in production plants

• Machine tending
  Loading and unloading CNC machines

• Smart factory and Industry 4.0
  Integration with AI systems, data analysis, and digital production control
