Fanuc M710iC 50

Robot details

The FANUC M-710iC/50 is a versatile 6-axis industrial robot designed for high-performance material handling, machine tending, palletizing, assembly, and general manufacturing applications. With a payload capacity of 50 kg and a maximum reach of 2,050 mm, it delivers excellent flexibility, speed, and reliability.

Paired with the renowned FANUC R-30iB controller, this robotic system ensures precise motion control, advanced programming capabilities, and seamless integration into automated production environments. The compact design, robust construction, and low maintenance requirements make the M-710iC/50 an ideal solution for manufacturers seeking to improve productivity and operational efficiency.

Key Features:

• 50 kg payload capacity
• 2,050 mm maximum reach
• 6-axis articulated robot
• FANUC R-30iB intelligent controller
• High-speed and high-precision operation
• Suitable for handling, machine loading, assembly, palletizing, and packaging
• Proven FANUC reliability and durability

The FANUC M-710iC/50 with R-30iB Controller is a 6-axis industrial robot engineered for medium-payload applications up to 50 kg. Its large working envelope, high repeatability, and advanced FANUC control technology make it suitable for automated material handling, machine tending, assembly, palletizing, and packaging operations. The R-30iB controller provides user-friendly programming, enhanced motion control, and reliable system performance for demanding industrial environments.

Robot applications

• Press tending
• Loading and unloading of parts
• Machining
• Handling of parts
• Polishing
• Palletising
• Measurement
• Assembly of parts
• Stud welding
• Plasma cutting

FANUC M-710iC/50 with R-30iB Controller

• Robot Type: 6-Axis Articulated Industrial Robot
• Controller: FANUC R-30iB
• Payload Capacity: 50 kg
• Maximum Reach: 2,050 mm
• Repeatability: ±0.03 mm
• Robot Weight: 560 kg
• Number of Axes: 6
• Mounting Options: Floor, Angle, or Inverted Mounting
• Protection Rating:
  • Body: IP54 (Optional IP67)
  • Wrist & J3 Arm: IP67
• Average Power Consumption: 3 kW
• Robot Structure: Slim wrist, rigid arm, compact footprint

Typical Applications

• Material Handling
• Machine Tending
• Assembly
• Palletizing
• Packaging
• Grinding & Polishing
• Deburring
• Waterjet Cutting
• Washing Operations

Benefits

The FANUC M-710iC/50 combines a generous working envelope with a 50 kg payload capacity, making it an ideal automation solution for medium-duty industrial applications. Its robust construction, high-speed performance, and reliable R-30iB controller ensure precision, productivity, and long-term operational efficiency.
