Robot details

The FANUC M-410iC/500 is a high-capacity 4-axis palletizing robot designed for ultra-heavy payload applications and high-throughput industrial environments. With a maximum payload of 500 kg and an extended reach of 3,143 mm, it is one of the most powerful robots in the FANUC palletizing series, ideal for handling large, bulky, or multi-product loads.

The robot features a rigid articulated structure and a hollow wrist design, allowing internal cable routing to reduce wear, prevent cable interference, and increase system reliability in demanding production lines.

Equipped with high-torque AC servo motors, the M-410iC/500 ensures stable motion dynamics, smooth acceleration, and consistent accuracy, achieving a repeatability of approximately ±0.05 mm according to ISO standards.

The system is controlled by the FANUC R-30iB Plus controller, which provides advanced processing performance, faster communication cycles, and integrated intelligent features such as vision systems, motion optimization, and collision avoidance. Its intuitive iPendant interface (iHMI) simplifies programming, setup, and diagnostics.

The M-410iC/500 is specifically engineered for:

• Ultra-heavy palletizing operations
• End-of-line automation
• Bulk material handling
• Warehouse and logistics automation

Its high inertia capacity and optimized kinematics make it ideal for large grippers and maximum load stability at high cycle speeds.

Robot applications

• Press tending
• Loading and unloading of parts
• Machining
• Palletising

General Technical Scheme

1. Robot Architecture

• Type: Articulated palletizing robot
• Axes: 4 (J1, J2, J3, J4)
• Drive system: Electric AC servo motors
• Mounting: Floor / pedestal

2. Core Specifications

• Payload: 500 kg
• Reach: 3143 mm
• Repeatability: ±0.05 mm
• Robot mass: 1910 – 2410 kg
• Protection: IP54

3. Axis Motion Range

• J1 (base): ±370°
• J2: ±144°
• J3: ±136°
• J4 (wrist): ±720°

4. Axis Speed (Maximum)

• J1: ~85 °/s (≈1.48 rad/s)
• J2: ~85 °/s (≈1.48 rad/s)
• J3: ~85 °/s (≈1.48 rad/s)
• J4: ~200 °/s (≈3.49 rad/s)

5. Controller (FANUC R-30iB Plus)

• High-performance industrial robot controller
• Multi-axis coordinated motion control
• Integrated intelligent functions (vision, safety, diagnostics)
• High-speed CPU and improved signal processing
• iPendant Touch with graphical interface (iHMI)
• Power supply: 200–575V AC, 3-phase
