MOTOMAN YASKAWA GP110 B
Robot details
The YASKAWA MOTOMAN GP110B is a powerful 7-axis industrial robot designed for advanced material handling, machine tending, press tending, and heavy-part processing applications. With a 110 kg payload capacity and a 2,236 mm horizontal reach, the GP110B provides exceptional flexibility through its unique 7-axis design, allowing enhanced obstacle avoidance and improved access to difficult work areas.
Controlled by the advanced YRC1000 controller, the GP110B delivers high-performance motion control, smooth trajectory planning, and intelligent automation capabilities for demanding manufacturing environments. Its additional axis offers increased articulation compared to conventional 6-axis robots, making it ideal for complex handling applications and production cells with limited space.
Designed for heavy-duty industrial automation, the GP110B features internally routed cables and air lines from the base to the upper arm, improving cable protection, increasing reliability, and reducing maintenance requirements. Its compact interference design allows closer robot placement and greater cell efficiency.
The GP110B is particularly suited for large-part handling, material transfer, machine loading, die casting operations, material cutting, trimming, and press automation where extended flexibility and payload capacity are critical.
Typical Applications
- Material Handling
- Machine Tending
- Press Tending
- Heavy Component Handling
- Part Transfer
- Die Casting Automation
- Material Cutting
- Material Trimming
- Dispensing Applications
- CNC Machine Loading and Unloading
- Automotive Manufacturing
- Metal Processing
- Industrial Automation
- Flexible Production Systems
The YASKAWA MOTOMAN GP110B is a 7-axis industrial robot with a 110 kg payload capacity and a 2,236 mm reach. Powered by the YRC1000 controller, it offers increased motion flexibility, obstacle avoidance, and superior access to restricted work areas. Designed for heavy-duty material handling, machine tending, die casting, and industrial automation, the GP110B delivers high performance, reliability, and efficient operation in advanced manufacturing environments.
Robot applications
General Data
| Specification | Value | |
|---|---|---|
| Robot Model | YASKAWA MOTOMAN GP110B | |
| Controller | YRC1000 | |
| Robot Type | 7-Axis Articulated Robot | |
| Payload Capacity | 110 kg | |
| Maximum Reach | 2,236 mm | |
| Vertical Reach | 3,792 mm | |
| Mounting Type | Floor Mount | |
| Internal Cable Routing | Yes | |
| Application Class | Heavy-Duty Material Handling |
Key Benefits
- 7-axis design for greater flexibility
- Improved obstacle avoidance
- Enhanced access to confined workspaces
- High payload capacity of 110 kg
- Internally routed cables and air lines
- Reduced interference radius
- Easy installation and maintenance
- Optimized for large-part handling
- Advanced control through YRC1000
