MOTOMAN YASKAWA GP25-12
Robot details
The YASKAWA MOTOMAN GP25-12 is a versatile high-speed 6-axis industrial robot designed for machine tending, material handling, assembly, dispensing, material removal, and advanced manufacturing applications. Combining a 12 kg payload capacity with an extended 2,010 mm reach, the GP25-12 provides exceptional flexibility for large work envelopes while maintaining high precision and productivity.
Powered by the advanced YRC1000 controller, the GP25-12 delivers optimized motion control, superior acceleration performance, and seamless integration into Industry 4.0 production environments. Its compact footprint and slim arm design enable installation in high-density robotic cells while minimizing interference with surrounding equipment.
The robot offers outstanding repeatability of up to ±0.03 mm, making it ideal for applications requiring precise positioning and consistent cycle times. Internal routing through the hollow-arm and wrist structure protects cables and pneumatic lines while simplifying system integration and maintenance.
With optional IP65/IP67 protection, the GP25-12 can operate reliably in harsh industrial environments and is frequently used in automotive manufacturing, logistics automation, packaging systems, CNC machine tending, additive manufacturing, and material removal applications.
Typical Applications
- Machine Tending
- Material Handling
- Assembly Operations
- Pick and Place
- Material Removal
- Dispensing Applications
- Additive Manufacturing
- CNC Machine Loading and Unloading
- Packaging Automation
- Automotive Manufacturing
- Logistics Automation
- Quality Inspection
- Production Line Automation
- Industrial Handling Systems
Robot applications
General Data
| Specification | Value | |
|---|---|---|
| Robot Model | YASKAWA MOTOMAN GP25-12 | |
| Controller | YRC1000 | |
| Robot Type | 6-Axis Articulated Robot | |
| Payload Capacity | 12 kg | |
| Maximum Reach | 2,010 mm | |
| Vertical Reach | 3,649 mm | |
| Repeatability | ±0.03 mm | |
| Robot Weight | 260 kg | |
| Power Supply | 2 kVA | |
| Protection Rating | IP65/IP67 (Optional) | |
| Mounting Options | Floor, Wall, Ceiling |
Axis Motion Range
| Axis | Motion Range |
|---|---|
| S-Axis | ±180° |
| L-Axis | +155° / -90° |
| U-Axis | +240° / -175° |
| R-Axis | ±180° |
| B-Axis | ±135° |
| T-Axis | ±360° |
Maximum Axis Speeds
| Axis | Maximum Speed |
|---|---|
| S-Axis | 210°/s |
| L-Axis | 210°/s |
| U-Axis | 220°/s |
| R-Axis | 435°/s |
| B-Axis | 435°/s |
| T-Axis | 700°/s |
