MOTOMAN YASKAWA GP50
Robot details
The YASKAWA MOTOMAN GP50 is a powerful and versatile 6-axis industrial robot designed for high-performance material handling, machine tending, assembly, dispensing, material removal, and heavy-duty automation tasks. With a 50 kg payload capacity and a maximum reach of 2,061 mm, the GP50 delivers the ideal combination of speed, precision, and flexibility for modern manufacturing environments.
Powered by the advanced YRC1000 controller, the GP50 offers fast processing performance, smooth path control, and intelligent motion optimization. Its robust mechanical structure and excellent payload-to-reach ratio allow manufacturers to increase throughput while maintaining exceptional accuracy and reliability.
With repeatability of ±0.03 mm, the GP50 is suitable for demanding industrial applications requiring accurate positioning and consistent cycle times. Its slim-arm design and reduced interference profile enable easy integration into compact robotic workcells and high-density production lines.
Available with optional IP65/IP67 environmental protection, the GP50 can operate reliably in harsh industrial environments exposed to dust, moisture, and contaminants. The robot's high wrist moments and inertia ratings make it an excellent solution for handling large and heavy components while maintaining superior performance and flexibility.
Typical Applications
- Material Handling
- Machine Tending
- Assembly Operations
- Part Transfer
- Press Tending
- Material Removal
- Material Cutting and Trimming
- Dispensing Applications
- Die Casting Automation
- CNC Loading and Unloading
- Automotive Manufacturing
- Packaging Automation
- Industrial Processing
- Production Line Automation
The YASKAWA MOTOMAN GP50 is a high-performance 6-axis industrial robot featuring a 50 kg payload capacity, 2,061 mm reach, and ±0.03 mm repeatability. Controlled by the advanced YRC1000 controller, the GP50 is ideal for material handling, machine tending, assembly, dispensing, die casting, and heavy-duty manufacturing operations. Its robust design, high payload capability, and Industry 4.0 compatibility make it a reliable solution for modern industrial automation.
Robot applications
General Data
| Specification | Value | |
|---|---|---|
| Robot Model | YASKAWA MOTOMAN GP50 | |
| Controller | YRC1000 | |
| Robot Type | 6-Axis Articulated Robot | |
| Payload Capacity | 50 kg | |
| Maximum Reach | 2,061 mm | |
| Vertical Reach | 3,578 mm | |
| Repeatability | ±0.03 mm | |
| Robot Weight | 570 kg | |
| Power Supply | 4 kVA | |
| Protection Rating | IP54/IP67 Standard, Optional IP65/IP67 | |
| Mounting Options | Floor, Wall, Ceiling, Tilt |
Axis Motion Range
| Axis | Motion Range | |
|---|---|---|
| S-Axis | ±180° | |
| L-Axis | +135° / -90° | |
| U-Axis | +206° / -80° | |
| R-Axis | ±360° | |
| B-Axis | ±125° | |
| T-Axis | ±360° |
Maximum Axis Speeds
| Axis | Maximum Speed |
|---|---|
| S-Axis | 180°/s |
| L-Axis | 178°/s |
| U-Axis | 178°/s |
| R-Axis | 250°/s |
| B-Axis | 250°/s |
| T-Axis | 360°/s |
