MOTOMAN YASKAWA GP88
Robot details
The YASKAWA MOTOMAN GP88 is a high-payload, high-performance 6-axis industrial robot designed for material handling, machine tending, assembly, dispensing, press tending, and heavy-duty manufacturing applications. With an impressive 88 kg payload capacity and a 2,236 mm reach, the GP88 combines strength, speed, and precision to increase productivity across a wide range of industries.
Powered by the advanced YRC1000 controller, the GP88 delivers intelligent motion control, fast cycle times, and outstanding reliability. Its compact design allows high-density cell layouts while maintaining a large working envelope, making it ideal for factories seeking maximum automation performance within limited floor space.
The robot offers exceptional repeatability of ±0.03 mm, ensuring accurate positioning for demanding industrial applications. High wrist moments and inertia ratings enable the handling of large workpieces, heavy tools, and complex end-of-arm tooling while maintaining precision and operational stability.
Pre-wired signal and pneumatic lines simplify installation and integration, reducing setup time and maintenance requirements. Optional IP65/IP67 protection allows reliable operation in harsh industrial environments where dust, moisture, and contaminants may be present.
Typical Applications
- Material Handling
- Machine Tending
- Assembly Operations
- Part Transfer
- Press Tending
- Dispensing Applications
- Material Cutting and Trimming
- Material Removal
- Die Casting Automation
- CNC Machine Loading and Unloading
- Additive Manufacturing
- Grinding and Polishing
- Automotive Manufacturing
- Industrial Processing
The YASKAWA MOTOMAN GP88 is a high-performance 6-axis industrial robot featuring an 88 kg payload capacity, 2,236 mm reach, and ±0.03 mm repeatability. Powered by the YRC1000 controller, the GP88 excels in material handling, machine tending, assembly, dispensing, press tending, and heavy-duty manufacturing applications. Its compact footprint, high payload capability, and fast cycle times make it an ideal solution for modern industrial automation and Industry 4.0 production environments.
Robot applications
General Data
| Specification | Value | |
|---|---|---|
| Robot Model | YASKAWA MOTOMAN GP88 | |
| Controller | YRC1000 | |
| Robot Type | 6-Axis Articulated Robot | |
| Payload Capacity | 88 kg | |
| Maximum Reach | 2,236 mm | |
| Vertical Reach | 3,751 mm | |
| Repeatability | ±0.03 mm | |
| Robot Weight | 630 kg | |
| Power Supply | 4 kVA | |
| Protection Rating | IP54/IP67 Standard, Optional IP65/IP67 | |
| Mounting Options | Floor, Wall, Ceiling, Tilt |
Axis Motion Range
| Axis | Motion Range | |
|---|---|---|
| S-Axis | ±180° | |
| L-Axis | +155° / -90° | |
| U-Axis | +90° / -80° | |
| R-Axis | ±360° | |
| B-Axis | ±125° | |
| T-Axis | ±360° |
Maximum Axis Speeds
| Axis | Maximum Speed |
|---|---|
| S-Axis | 170°/s |
| L-Axis | 140°/s |
| U-Axis | 160°/s |
| R-Axis | 230°/s |
| B-Axis | 230°/s |
| T-Axis | 350°/s |
