MOTOMAN YASKAWA MH900
Robot details
The YASKAWA MOTOMAN MH900 is an ultra-heavy-duty 6-axis industrial robot engineered for large-scale material handling, machine tending, part transfer, and heavy manufacturing applications. With an outstanding 900 kg payload capacity and an extended 4,683 mm horizontal reach, the MH900 is one of the highest-capacity robots in the Yaskawa MOTOMAN range.
Designed with a robust parallel-link construction, the MH900 delivers superior rigidity, stability, and load-handling performance for moving extremely large and heavy components. It is widely used for handling automotive body structures, agricultural equipment, steel fabrications, castings, weldments, and palletized loads.
The robot is controlled by the high-performance YASKAWA DX200 controller, offering advanced motion control, flexible programming, Functional Safety Unit (FSU) capabilities, and proven reliability in demanding industrial environments.
Main Applications
Material Handling
- Heavy component transfer
- Steel structure handling
- Large casting manipulation
- Industrial logistics
- Production line automation
Machine Tending
- Large CNC machine loading
- Machine unloading
- Flexible manufacturing systems
- Heavy industrial automation
Part Transfer
- Automotive body transfer
- Weldment handling
- Fixture positioning
- Production process automation
Heavy Manufacturing
- Agricultural machinery production
- Construction equipment manufacturing
- Steel fabrication
- Heavy assembly operations
Jigless Applications
- Robot-to-robot positioning
- Large workpiece alignment
- Multi-robot production systems
- Flexible manufacturing cells
Key Advantages
✅ Massive payload capacity of 900 kg.
✅ Long horizontal reach of 4,683 mm.
✅ Vertical reach of 6,209 mm.
✅ Parallel-link construction for exceptional rigidity.
✅ High moment and inertia capacity for oversized parts.
✅ Ideal for machine tending and heavy-duty handling.
✅ Heavy-duty bearings ensure smooth arm rotation.
✅ Designed for demanding industrial environments.
✅ Functional Safety Unit (FSU) support available.
✅ Proven DX200 platform reliability.
DX200 Controller Features
- Advanced robot motion control
- INFORM programming language
- Functional Safety Unit (FSU)
- Multi-task processing
- Ethernet communication
- Fieldbus integration
- User-friendly programming interface
- High system reliability
- Easy maintenance
- Proven industrial performance
Why Choose a Used or Refurbished YASKAWA MH900?
A professionally refurbished YASKAWA MH900 with DX200 controller offers a cost-effective solution for manufacturers requiring ultra-heavy payload automation without the investment associated with a new robotic system.
Benefits
- Lower acquisition cost
- Fully tested and inspected systems
- Proven DX200 reliability
- Worldwide spare parts availability
- Reduced lead times
- Excellent ROI
- Sustainable industrial automation investment
The MH900 is ideal for handling vehicle frames, large weldments, steel structures, castings, agricultural machinery, and oversized industrial components.
Robot applications
General Specifications
| Feature | Value | |
|---|---|---|
| Manufacturer | YASKAWA MOTOMAN | |
| Model | MH900 | |
| Controller | DX200 | |
| Robot Type | 6-Axis Heavy Payload Industrial Robot | |
| Payload Capacity | 900 kg | |
| Horizontal Reach | 4,683 mm | |
| Vertical Reach | 6,209 mm | |
| Repeatability | ±0.5 mm | |
| Robot Weight | 9,550 kg | |
| Power Requirement | 35 kVA | |
| Mounting Type | Floor Mounted | |
| Number of Axes | 6 |
Axis Speeds
| Axis | Maximum Speed | |
|---|---|---|
| S | 45°/s | |
| L | 30°/s | |
| U | 30°/s | |
| R | 50°/s | |
| B | 50°/s | |
| T | 70°/s |
Protection & Construction
| Feature | Specification | |
|---|---|---|
| Structure | Parallel-Link Design | |
| Mounting | Floor | |
| Body Protection | IP30 | |
| Wrist Protection | IP67 | |
| Heavy-Duty Bearings | Yes |
